CARBURETTOR REPAIR KIT - GT250. SOME PARTS FIT T250

DESCRIPTION: Carburettor repair kit. Contains 113 main jet, number 25 pilot jet, Y40 (5CN3-2) needle, float needle valve, air screw, float bowl gasket, carb top gasket (not for all models) and carb to cylinder barrel 'O' ring (not for all models).

This is a quality kit, made in Japan. Not to be confused with some of the cheap kits available from ebay.

For 'A' models, you will need either main jet 92.5 & pilot jet 30 OR left hand main 97.5, right hand main 95, pilot jet 30. Please check before ordering. See below for jets.

For 'B' & 'C' models, you will need main jet 95 & pilot jet 30.

The following parts fit T250 2/R/J models:

Needle valve assembly, pilot jet, needle jet, float bowl gasket, carb 'O' ring.

Please note that you will have to ensure that the jetting is suitable for your machine. Suzytwo will not be responsible for any damage caused by incorrect jetting on your machine as a result of using this kit. All jetting specifications are from Suzuki parts catalogues, based on stock engines.

For float bowl screws, see below.

CONDITION: New, pattern parts.

PART NUMBER: 13200-18653.

FITS MODEL(S):

GT250 K/L/M.

GT250 A/B/C, see notes above.

T250 2/R/J - NOT MARK 1, see notes above.

MODEL YEARS AND DATES ARE APPROXIMATE

Please note that we have tried our best to indicate the correct model and model year, but it could be wrong. Please check that the part number is suitable for your machine before you order.
